Asus Prime H610M-A LGA 1700 DDR4 WiFi mATX Motherboard

Asus Prime PRIME H610M-A WIFI D4 Desktop Motherboard - Intel H610 Chipset - Socket LGA-1700 - Micro ATX - Pentium Gold, Celeron Processor Supported - 64 GB DDR4 SDRAM Maximum RAM - DIMM, UDIMM - 2 x Memory Slots - Gigabit Ethernet - IEEE 802.11a/b/g/n/ac - HDMI - DisplayPort - 4 x SATA Interfaces

ASUS Prime series motherboards are expertly engineered to unleash the full potential of 13th& 12thGeneration Intel®processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, Prime H610 provides users and PC DIY builders a range of performance tuning options via intuitive software and firmware features.

FLEXIBILITY Comprehensive controls form the foundation of the ASUS Prime series. The Prime H610 motherboard packs flexible tools to tune every aspect of your system, enabling performance tweaks to perfectly match the way you work to maximize productivity. All-Around Energy Efficiency The Energy Processing Unit (EPU) automatically optimizes power consumption and maximizes energy savings with Away mode - a smart setting that creates an extreme energy-saving scenario by shutting down unused I/O controllers. UEFI BIOS


The renowned ASUS UEFI BIOS provides everything you need to configure, tweak and tune your system. It offers intelligently simplified options for PC DIY beginners, as well as comprehensive features for seasoned veterans.Advanced Tuning for Serious Tweakers


An intuitive Advanced mode offered via the UEFI lets you take complete control. A built-in search feature makes it easy to find options, and various advanced functions let you intelligently make nuanced adjustments so you can dial in performance just the way you want.



Features

Intel
^®
LGA 1700 socket:
Ready for 13^th& 12^thGen Intel^® processors
Comprehensive cooling:
VRM heatsink, PCH heatsink and Fan Xpert 2+
Ultrafast connectivity:
32Gbps M.2 slot, Intel^®1 Gb Ethernet, WIFI 5 and USB 3.2 Gen 2 ports
Aura Sync RGB:
Onboard addressable Gen 2 headers for RGB LED strips, easily synced with Aura Sync-capable hardware

Guides & Documents

Brochure

With the exception of information relating to Ingram Micro pricing and stock availability, all product information has been provided by the relevant original equipment manufacturer and/or vendor and not Ingram Micro, and Ingram Micro has included it on this Website as a convenience only. The Customer should confirm all product descriptions and specifications with the relevant original equipment manufacturer or vendor before purchase.
Technical Specs
Audio
Audio Channels 7.1
I/O Controller
Controller Type Serial ATA/600
Video
Onboard Video CPU Dependent Video
Miscellaneous
Environmentally Friendly Yes
Environmental Certification RoHS
Brand Compatibility Intel
Physical Characteristics
Form Factor Micro ATX
Width 243.8 mm
Depth 210.8 mm
Onboard Interfaces
Number of SATA Interfaces 4
Total Number of Onboard USB Ports 5
Number of Onboard USB 2.0 Ports 3
Number of M.2 Interfaces 2
Network & Communication
Bluetooth Yes
Gigabit Ethernet Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11a/b/g/n/ac
Bluetooth Standard Bluetooth 5.0
I/O Expansions
Number of PCI Express x1 Slots 1
Number of Total Expansion Slots 2
Number of PCI Express x16 Slots 1
PCI Express Standard PCI Express 3.0
PCI Express 4.0
Total Number of PCI Express Slots 2
Interfaces/Ports
S/PDIF Yes
HDMI Yes
HDMI Version 2.1
Number of Network (RJ-45) Ports 1
DisplayPort Yes
Total Number of USB Ports 6
Number of USB 3.2 Gen 2 Type-A Ports 2
General Information
Product Type Desktop Motherboard
Manufacturer Part Number PRIMEH610MAWIFID4
Manufacturer Website Address http://www.asus.com/au
Manufacturer ASUS Computer International
Product Model PRIME H610M-A WIFI D4
Product Name PRIME H610M-A WIFI D4 Desktop Motherboard
Product Line Prime
Brand Name Asus
Processor & Chipset
Processor Supported Pentium Gold
Core
Celeron
Total Processor Supported 1
Processor Socket Socket LGA-1700
Chipset Manufacturer Intel
Chipset Model H610
Processor Generation Supported 12th Gen
12th Gen
13th Gen
13th Gen
Memory
Maximum Memory Supported 64 GB
Memory Technology DDR4 SDRAM
Number of Memory Slots 2
Memory Form Factor DIMM
UDIMM
Memory Speed Supported 2400 MHz
2133 MHz
2666 MHz
3200 MHz
3000 MHz
2800 MHz
2933 MHz
